HDL KNX 4CH 10A Curtain Actuator

KNX

HDL KNX 4CH 10A Curtain Actuator

0.00 Lei

Stoc: 10

KNX 4CH 10A Curtain Actuator is in full compliance with Chinese and European safety standards and KNX protocol. This series of products has the characteristics of high power (10A), low consumption, and high reliability. Basic Parameters Working voltage 21~30V DC Working current 12mA/30V DC Input voltage 120V/240V AC (50/60Hz) Output channel 4CH/10A Communication KNX Output terminal Line in, line out cable for each channel 2.5-4mm2 Cable diameter of KNX terminal 0.6 - 0.8mm Electrical life time ＞100000 Mechanical life time ＞100000 External Environment Working temperature -5℃~45℃ Working relative humidity ≤90% Storage temperature -20℃~60℃ Storage relative humidity ≤93% Specifications Dimensions 144mm×90mm×64mm Net weight 362g Housing material Nylon (PA66) Installation 35mm DIN rail installation Protection rating (Compliant with EN 60529) IP20
