Annular Gateway

Annular Gateway supports access to the LAN via WI-FI or RJ45 network port, and it supports Zigbee3.0 standard device and be compatible with the HA standard. The gateway can manage and control Zigbee standard device and synchronize the status. The gateway has dry contacts and RS485 interfaces, and provides scenes, logic, security, and device binding functions, which can operate normally even when the network is disconnected. The gateway and the Cloud communicate through HTTPS and MQTT data; it supports the function of local RTC real-time clock. DC power supply: 12VDC AC power supply: 100~240VAC (50/60Hz) Power consumption: ≤5W Communication: Zigbee 3.0 Operation system: Linux 3.18.29 Kernel Wireless transmission power: +10dbm Indoor communication distance (barrier free): ≤50m Working frequency: 2.4GHz Protection rating (Compliant with EN 60529): IP20 Working temperature: -5℃~45℃ Working relative humidity: ≤90%RH, no condensation Dimensions: 186×106×23.8 (mm) Net weight: 179g Housing material: PC Installation: 144 wall box installation Hardware information: 580MHz MIPS24KEC chip, 128M RAM, 16M Flash
